Surface Grinding Machine with Horizontal Spindle
Model: MX-7160
Max. Workpiece to bi Groud: 1250x600x600mm
Longitudinal Motion Stroke (Hydraulic): 1350mm
Distance From Table Surface To Spindle Center: 780mm
The Max. Stroke of Transverse Motion: 650mm
Spindle Speeds: 1440r/min
Wheel Size (Dia*Width*Bore): Φ400x50xΦ203mm
Machine Size: 3000x1950x2400mm
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
MX-7160 surface grinding machine with horizontal spindle and rectangular table is an efficient hydraulic transmission grinding machine tool. It adopts advanced technology and design and can be widely used in various machining, auto parts, fixtures, magnetic steel, molds, and other parts processing industries.
Compared with the original manual grinder, MX-7160 horizontal surface grinder adds a fast lifting mechanism on the basis of vertical lifting of the grinding head, which greatly improves production efficiency. At the same time, it also has the characteristics of high precision and high stability, which can meet different processing requirements.
Surface Grinding Machine With Horizontal Spindle And Rectangular Table MX-7160
|
MX-7160 |
Semi-automatic |
Fully-automatic |
|
Vertical |
Rapid movement and manual |
AC servo motor |
|
Cross |
Auto intermittent |
Motor |
|
Longitudinal |
Hydraulic |
Hydraulic |
|
Controller |
-- |
GS-PLC Touch |
Technical Parameters
|
Model |
MX-7160 |
MX-7160x14 |
MX-7160x16 |
MX-7160x20 |
|
Max. Workpiece to bi Groud |
1250x600x600mm |
1400x600x600mm |
1600x600x600mm |
2000x600x600mm |
|
Longitudinal Motion Stroke (Hydraulic) |
1350mm |
1500mm |
1700mm |
2100mm |
|
Distance From Table Surface To Spindle Center |
780mm |
780mm |
780mm |
780mm |
|
Vertical Feed Wheel Movement Per Lap |
1mm |
1mm |
1mm |
1mm |
|
Vertical Feed Hand Wheel Per Movement |
0.01mm |
0.01mm |
0.01mm |
0.01mm |
|
The Max. Stroke of Transverse Motion |
650mm |
650mm |
650mm |
650mm |
|
Horizontal Intermittent Movement Speed (Stepless) |
0.5-3m/min |
0.5-3m/min |
0.5-3m/min |
0.5-3m/min |
|
Longitudinal Velocity (Stdpless) |
3-30m/min |
3-30m/min |
3-30m/min |
3-30m/min |
|
Spindle Speeds |
1440r/min |
1440r/min |
1440r/min |
1440r/min |
|
Wheel Size (Dia*Width*Bore) |
Φ400x50xΦ203mm |
Φ400x50xΦ203mm |
Φ400x50xΦ203mm |
Φ400x50xΦ203mm |
|
Grinding Head Motor Power |
7.5kw |
7.5kw |
7.5kw |
7.5kw |
|
Total Motor Power |
14.5kw |
14.5kw |
14.5kw |
16kw |
|
Oil Pump Motor Power |
5.5kw |
5.5kw |
5.5kw |
5.5kw |
|
Max. Loading Capacity of Table |
1010kg |
1290kg |
1780kg |
2100kg |
|
Net Weight |
5500kg |
6500kg |
7000kg |
8000kg |
|
The Machined Surface of The Base of Parallelism |
1000:0.015mm |
1000:0.015mm |
1000:0.015mm |
1000:0.015mm |
|
Surface Roughness |
Ra0.63μm |
Ra0.63μm |
Ra0.63μm |
Ra0.63μm |
|
Machine Size |
3000x1950x2400mm |
4600x1950x2400mm |
4600x1950x2400mm |
5250x1950x2400mm |
